Grain Drying Tower
A grain dryer is a specialized machine designed for grain drying, mainly used to remove moisture from grain to maintain its quality and extend storage life. Equipped with an advanced hot air circulation system, the machine can quickly and evenly dry grain while ensuring excellent grain quality.
Grain Drying Tower
A grain dryer is a specialized machine designed for grain drying, mainly used to remove moisture from grain to maintain its quality and extend storage life. Equipped with an advanced hot air circulation system, the machine can quickly and evenly dry grain while ensuring excellent grain quality.
5HL-120 And 5HL-150 Grain Drying Towers
The product information and parameters below are transcribed from the customer-provided workbook.
| Specification | 5HL-120 Continuous Flow Grain Dryer | 5HL-150 Continuous Flow Grain Dryer |
|---|---|---|
| Overall Dimensions (mm) | 3080 × 2480 × 17500 | 3080 × 2480 × 18750 |
| Effective Volume (m³) | 63 | 71 |
| Batch Processing Capacity (t) | / | / |
| Daily Processing Capacity (t/day) | ≥120 | ≥150 |
| Structure Type | Continuous Flow Type | Continuous Flow Type |
| Moisture Reduction Capacity | Rice: ≥3% Wheat: ≥3.5% Corn: ≥2% | Rice: ≥3% Wheat: ≥3.5% Corn: ≥2% |
| Operating Hot Air Temperature Range (°C) | 80-160 | 80-160 |
| Heat Source | Diesel Fuel / Biomass Oil / Coal / Biomass Pellets / Natural Gas | Diesel Fuel / Biomass Oil / Coal / Biomass Pellets / Natural Gas |
| Total Power (kW) | 49.95 | 59.95 |
| Main Configuration | PLC control system + variable frequency grain metering device, soft-start fan system, automatic & manual operation modes, dual temperature control points, real-time moisture analysis, real-time grain bin video monitoring. | PLC control system + variable frequency grain metering device, automatic & manual operation modes, soft-start fan system, dual temperature control points, real-time moisture analysis, real-time grain bin video monitoring. |
The data above is transcribed from the customer-provided product information workbook. Final supply parameters are subject to the technical agreement and contract confirmed by both parties.
Grain Drying Tower Delivery Sites
Key stages from lifting and structural installation to heat source and fan assembly.
Configure A Grain Drying Tower
Please provide the grain type, initial moisture, daily throughput, available heat source and site conditions.
